集工(gong)作设(she)想(xiang)创造、生厂、发(fa)卖办(ban)事人
于分离式的专情于石料采矿和加工制作机气极品装备的之域级高新技术厨艺企业
| 称号 | Name | 单元/Unit | 2QYK-3600 |
2QYK-3300 |
2QYK-3600 |
2QYK-4000/4200 | 2QYK-5000 |
| 范例 | Type | A/B/C/D |
A/B/C/D |
A/B/C/D |
A/B/C/D |
A/B/C/D |
|
| 锯片直径 | Blade diameter |
mm |
Φ3000 | Φ3300 | Φ3600 |
Φ4000/Φ4200 |
Φ5000 |
| 最大切割深度 | Max.cutting depth |
mm |
1250 | 1400 | 1500 | 1750/1850 | 2250 |
|
设备主机工率 |
Power ofmain motor |
kw | 55x2 | 55x2 | 55x2 | 65X2 | 65X2 |
|
液压油泵电气功效 |
Power of pump motor |
kw |
3.5 | 3.5 | 3.5 | 4 | 4 |
| 路程机电功率 |
Power of stroke motor |
kw |
2.2 | 2.2 | 2.2 | 3 | 4 |
| 纵向换轨机电功率 |
|
kw |
0.75x2 | 0.75x2 | 0.75x2 | 1.1X2 | 1.1X2 |
|
零件加工工作电压 |
Gross power |
kw |
117.2 | 117.2 | 117.2 | 139.2 | 140.2 |
|
形状图片尽寸 |
Dimensions(LxWxH) |
mm | 3200x2100x2800 | 3500x2200x3200 | 3800x2200x3100 | 420X2100X3500 | 5200X2200X4200 |
|
所需要的零部件使用 |
Gross weight |
kg | 7000-8500 | 7000-8500 | 7500-10000 | 9500-11500 | 9500-12500 |
| 切割宽度 | Cutting width of TypeA |
mm |
1360-1900 | 1360-1900 | 1360-1900 | 1950-2450 | 2000-2500 |
|
|
TypeB |
mm |
1800-2300 | 1800-2300 | 1900-2400 | 2400-2900 | 2400-2900 |
|
|
TypeC |
mm |
2200-2700 | 2200-2700 |
2300-2800 |
2800-3300 | 2800-3300 |
|
|
TypeD |
mm |
2700-3200 |
2700-3200 |
2700-3200 | 3200-3700 | 3200-3700 |
| 一米四机台 |
|
|
|
|
|
|
|
|
零件图信噪比 |
Gross weight |
kg |
7000 | 7500 | 7800 | / | / |
| 图案尺寸规格 | Dimensions(LxWxH) |
mm |
3200z1500z2630 |
3500x1500x2880 |
3700x1500x3050 |
/ | / |
|
切割工作大小 |
Cutting width |
mm |
1380-1880 | 1380-1880 | 1380-1880 | / | / |
| 四驱机型 |
|
|
|
|
|
|
|
| 纵横驱动机电功率 |
|
kw | 1.5x2 | 1.5x2 | 1.5x2 | 1.5X2 | 1.5X2 |
| 总功率 |
Gross power |
kw | 116.5 | 116.5 | 116.5 | 137 | 137 |
